Nrhiav rau lub teeb yuag, corrosion-cov khoom siv aluminium uas muaj kev ua tau zoo?
Aluminium 1050 H14 aluminium coil, ntawv, thiab phajmuab los ntawmGNEEyog siv dav hauv cov ntawv hlau ua haujlwm, cov khoom siv tshuaj lom neeg, thiab kev siv vaj tse nyob qhov twg yuav tsum muaj lub zog nruab nrab thiab siab purity.
Txheej txheem cej luam ntawm 1050 H14 Aluminium Chev, Ntawv thiab Phaj
Aluminium alloy 1050belongs rau lub1xxx series ntshiab txhuas alloys, muaj qhov tsawg kawg nkaus ntawm99.5% aluminium. CovH14 zogqhia tias cov khoom tau uaua hauj lwm-hardened los ntawm dov mus rau ib nrab- mob hnyav, tsis muaj annealing tom ntej.
Ua tsaug rau nws cov ntsiab lus siab aluminium,1050 H14 txhuas phaj thiab kaujmuab cov txiaj ntsig tseem ceeb hauv qab no:
Lub teeb nyhav
Zoo heev hluav taws xob thiab thermal conductivity
Siab corrosion kuj
Zoo ductility thiab formability
Bright, heev reflective nto tiav
Thaum raug huab cua, aluminium ib txwm tsim cov txheej txheem oxide tuab, muab kev tiv thaiv los tiv thaiv corrosion. Qhov no ua rau1050 H14 aluminium ntawvhaum rau ob qho tib si sab hauv tsev thiab sab nraum zoov ib puag ncig.
Qhov tseem ceeb ntawm 1050 H14 Aluminium Phaj
Aluminium alloy yog ib txwm mos, tab sis me me ntxiv ntawm cov ntsiab lus xws li tooj liab, magnesium, silicon, manganese, thiab zinc pab txhim kho kev ua haujlwm thaum tswj kev ua haujlwm zoo.
1050 H14 aluminium coil thiab ntawvyog cov khoom siv hluav taws xob zoo tshaj plaws muaj, ua rau lawv zoo tagnrho rau cov ntawv thov xws li cov khoom lag luam precision mus rau cov khoom siv niaj hnub.
Kev siv 1050 H14 Aluminium Coil thiab Phaj
Aluminium 1050 H14 txhuas ntawv thiab phajFeem ntau siv rau hauv daim ntawv thov uas xav tau lub zog nruab nrab thiab zoo heev corrosion kuj:
Cov txheej txheem tshuaj cog khoom siv
Cov thawv ntim khoom noj khoom haus
Pyrotechnic hmoov siv
Architectural flashings
Teeb thiab teeb pom kev zoo reflectors
Cable sheathing
Tshuaj muaj pes tsawg leeg ntawm 1050 H14 Aluminium Phaj
| Element | % Tam sim no |
|---|---|
| Copper (Cu) | 0 – 0.05 |
| Magnesium (Mg) | 0 – 0.05 |
| Silicon (Si) | 0 – 0.25 |
| Hlau (Fe) | 0 – 0.40 |
| Manganese (Mn) | 0 – 0.05 |
| Zinc (Zn) | 0 – 0.07 |
| Titanium (Ti) | 0 – 0.05 |
| Aluminium (Al) | Qhov nyiaj tshuav (Ntau dua lossis sib npaug rau 99.5%) |
Mechanical Properties ntawm 1050 H14 Aluminium Sheet
(BS EN 485-2: 2008, Thickness 0.2-6.0 hli)
| Khoom | Tus nqi |
|---|---|
| Pov thawj Stress | Ntau dua lossis sib npaug li 85 MPa |
| Tensile zog | 105-145 MPa |
| Brinell Hardness | 34 HB |
| Elongation (A) | Ntau dua lossis sib npaug li 12% |
Cov khoom siv kho tshuab saum toj no siv rau cov khoom siv hauv H14 mob.
Lub cev muaj zog ntawm 1050 H14 Aluminium Phaj
| Khoom | Tus nqi |
|---|---|
| Qhov ntom | 2.71 kg/m³ |
| Melting Point | 650 degree |
| Modulus ntawm Elasticity | 71gp ua |
| Hluav taws xob Resistivity | 0.0282 × 10⁻⁶ Ω·m |
| Thermal conductivity | 222 W/m·K |
| Thermal Expansion | 24 × 10⁻⁶ /K |
Alloy Designations rau 1050 Aluminium Phaj
Aluminium alloy 1050tseem paub los ntawm cov npe hauv qab no thoob ntiaj teb:
AW 1050A
S1B
A91050
Fabrication Performance ntawm 1050 H14 Aluminium Sheet
| Txheej txheem | Kev ntsuas |
|---|---|
| Kev ua haujlwm txias | Zoo heev |
| Machineability | pluag |
| Gas Vuam | Zoo heev |
| Arc vuam | Zoo heev |
| Kuj Vuam | Zoo heev |
| Brazability | Zoo heev |
| Solderability | Zoo heev |
Temper Information rau 1050 H14 Aluminium Phaj
Kev npau taws tshaj plaws rau1050 txhuas phaj thiab coilyog:
H14- Ua haujlwm- hardened los ntawm dov mus rau ib nrab- mob hnyav, tsis yog annealed tom qab dov.
Qhov no temper muab ib tug sib npaug ntawm lub zog thiab formability, ua rau nws haum rau ntau yam kev lag luam thiab architectural siv.
Muab Cov Ntawv ntawm 1050 H14 Aluminium Coil thiab Ntawv
GNEE muab txhuas alloy 1050-H14 nyob rau hauv cov ntaub ntawv hauv qab no:
Plain aluminium ntawv
Daim ntawv dawb nrog ib zaug - sab PVC txheej
Stucco aluminium ntawv
Stucco daim ntawv nrog ib zaug - sab PVC txheej
Ntshai
Tag nrho cov khoom siv tau ntsibAS/NZS 1734: 1997thiab sib npaug rauTS EN 573-1cov qauv rau cov ntawv tiaj tus, coiled ntawv, thiab phaj.
Vim li cas thiaj xaiv GNEE rau 1050 H14 Aluminium Phaj?
Raws li tus kws tshaj lij aluminium tsum,GNEEmuab ruaj khov- zoo1050 H14 aluminium coil, ntawv, thiab phajnrog cov tshuaj muaj pes tsawg leeg zoo ib yam, txhim khu kev qha txhua yam kev ua tau zoo, thiab kev xaiv qhov chaw yooj yim. Peb cov khoom siv dav siv hauv kev lag luam tshuaj, vaj tsev, hluav taws xob, thiab kev lag luam.
Hu rau GNEE rau 1050 H14 Aluminium Chev thiab Phaj
Yog koj xav tautus nqi, cov qauv, cov ntaub ntawv kev, lossis kev cai tshwj xeebrau1050 H14 txhuas ntawv los yog kauj, thov hu rauGNEEhnub no.
Peb pab neeg tau npaj txhij los txhawb koj qhov project nrog txhim khu kev qha aluminium kev daws teeb meem thiab xa khoom sai thoob ntiaj teb.
